Zepoxy 700 is a low gloss epoxy system for general purpose coatings and thin castings. This system offers a moderate open time, medium viscosity, good wetting characteristics, excellent adhesion, and excellent mechanical strength.
|Appearance Part A||Visual||Medium viscosity, clear to light yellow liquid|
|Appearance Part B||Visual||Low viscosity, yellow liquid|
|Mix ratio (Part A: Part B)||Theoretical||100: 50|
|*Mix viscosity @ 25°C||ASTM D 2196||1000 – 5000 cPs|
|*Flash Point||ASTM D 93||>135°C|
|Coverage per KG||Theoretical||9 SFT @ 1mm thick|
|Recommended maximum casting thickness||–||5mm|
|*Pot life (300g mix) @ 30°C||–||45 min|
|*Hardening time||–||24 hours|
|*Full Cure||–||7 days|
|*Flexural Strength (MPa)||ASTM D 790||100.0|
|*Compressive Strength (MPa)||ASTM D 695||85.0|
These are typical results under laboratory conditions.
At 40°C gel time will be reduced to half, in case of increased temperatures, pouring should be planned accordingly.
The mixing ratio must be accurately followed to achieve perfect results. It is not possible to change the ratio which would result in the epoxy not drying properly and lower mechanical properties. Pour the hardener first and then the resin. The mixed components should be thoroughly mixed for 3-4 minutes to ensure an even consistency. To avoid development of bubbles slowly mix for 5-10 mins. Once the epoxy is mixed and poured gently pass warm air from a heat gun or hair dryer on slowest speed setting, this will assist in removal of any bubbles generated during mixing.
1.5 KG Sets Part A 1 KG
Part B 500g
15 KG Sets Part A 10 KG
Part B 5 KG
45 KG Sets Part A 30 KG
Part B 15 KG
HEALTH AND SAFETY
Dispose containers of the materials as per local laws, rules, and regulations. Use gloves, safety masks and other safety apparel as per health and safety laws. For further assistance, please refer to the MSDS of the product for further health and safety information.
